passive transformer channels that shift signal level;
bidirectional audio path;
send and return your guitar pedals (may need gain);
apply DC offset to saturate your audio;
unbalanced, use TS 1/4 plug;
available in 3U Quad and PulpLogic 1U Tile formats
Mannequins RIP Is a legend, but it's gone.
Module does not draw current
45 mm Depth
Tactile Patching Interface
Lines takes another approach of control than expressive cv generation, it's a tactile patching interface.
Your patch is now linked to your muscle memory, as swift as your movements.
diagonal layout ensures ultimate versatility with easy hand shapes;
+5V normalled to input 1/3, -5V normalled to input 2/4;
spread and divide an input signal by routing it to multiple outputs;
bi-color LEDs display signals of each output.
[playing patch is next lvl]
A collection of real time functions integrated with hand gestures and a trigger input.
Go work your muscle memories into your synth patch.
hold REC button to record;
a quick tap on REC clears the memory;
realtime gestures override playback and interrupts EOL trigger output;
when memory is clear, EOL goes high to indicate the absence of gestures;
hold REC for 4 secs to switch between LFO and ENV mode;
slew smoothes the slopes;
max recording time : 2.22 seconds
It’s a controller, lfo, envelope, clock source, trigger delay. But here the slopes are played by you.
[bring performance gestures to modular system]
10 mm Depth
Circuit-Bent Digital Waveguide
millions of sweet spots
new feature in firmware 2016-04-15 :
-hold type button while powering up for D Major pentatonic tuning like a Chinese Zither
Dual Passive LPG
It’s a dual 1-pole vactrol based LPG / VCA module that only takes 2 HP space. It is totally passive, no power required. The electronic components values are carefully picked to be musical and beautiful, by feeding it a trigger you get a the lovely natural decay of a vactrol. Fill all your blank spaces in your system with this very useful and handy little module.
Arcade Manifold is a passive multi-functional controller both available in Eurorack and Standalone format.
There are 4 identical channels. Each channel can do :
l Connect signal when button pushed;
l Signal pull to ground when button pushed.
This would result in normal on and normal off operation for the button.
By using 1/8 or 1/4 jacks, you can use banana jacks to passive mix signals from different channels. Mixing can happen at 2 places :
l At input : sending the same mix to different outputs, controlling which channel to send to with buttons;
l At output : sending the same mix to differerent outputs, controlling which signal presents in the mix with buttons.
Combining all these features, you can customize your own signal routes that can be played live with speed and precision. Arcade switches are from SANWA, and of the highest quality.
With some modular synthesis instrument that react to ground connection, like Ciat-Lonbarde instruments, you can control them without any input! For example, you can trigger the sound of Gongue and AVDog on Plumbutter, or alter the timber of Sidrassi with its glitch inputs, etc.
It can also be used as multiple and format jumbler.
84*6 Programmer & CV / Gate Sequencer with multiple modes
easy to play interface + intuitive workflow + deep feature set = essential for any setup
84 page x 6 outputs
manual recall that can be quantized to external triggers
auto mode 1 : sequencer and arp with internal & external clock / hold / reset
- 1-1 : classic step sequencer that goes between any 2 pages
- 1-2 : arpeggiator which scroll through the pages in the same order of touch
- 1-3 : custom step sequencer up to 64 step, pages in any order you want, with realtime touch-to-hold feature
- 1-4 : 6 track gate sequencer with track mute, perfect for drum
auto mode 2 : pressure
- 2-1 : 6 pressure outputs
- 2-2 : 3 step playable sequencer with timing controlled by pressure
auto mode 3 : looper
- realtime looper with 5s recording time and external reset input
just requires positive power supply
available in Eurorack and Standalone Banana formats
It’s a waste to spend brain picking right length of patch cable prior to patching, a hassle when longer cables knot each other in your backpack, and a pity when high profile plugs prevent closing case with your modular patched.
Welcome spring patch cables.
length : 15cm to 60cm+
low profile L shape plug
4 way multiple
modular synthesists' keychain
custom made for high quality and environment standard
totally flat on the back
hassle and gap free
install with double sided tape or screws without problem
